10 MVA transformer is relatively uncommon in daily life. Today I will describe it from its definition, type, specification, weight, price, etc.
What Does MVA Stand For?
MVA stands for megavolt-amperes. It is the unit of measurement for the electrical load in an engineering system. 1 MVA is equivalent to a million volt-amperes. On the other hand, 10mVA is 10,000,000 volt-amperes.
A transformer that's measured in MVA is usually a distribution transformer. The 10 MVA transformer is one of the most common distribution transformers. It is typically used to generate electricity for industrial businesses that require a strong and consistent source of power.
Without a 10 MVA transformer, these businesses would not be able to function at full capacity. Therefore, 10 MVA transformers play a crucial role in ensuring that these businesses can continue to operate smoothly and efficiently.
Read more: Basic Guide to kVA Transformer
What is a 10 MVA Transformer?
A 10MVA transformer is a distribution transformer that can help generate electricity supply to larger industries and manufacturing plants. Volt Amperes (VA) is the measurement unit for the amount of electrical load in engineering standards.
You can also use the metric prefixes' kilo-' and 'mega-' when referring to the 10mva transformer. 1 kilo volt ampere (kVa) is equivalent to 1,000Va. Subsequently, 1 MVA is equal to 1,00,000Va. Therefore, one MVA will require 1,000kVa. So, for example, if you have a 10,000kVa demand, you will need 10mva.
Daelim understands that you need to meet the needs for a continuous power supply. We are aware of the challenges and needs our clients and customers face every day. Daelim can provide the best transformer solution for your power station, factory, and energy storage system.
Learn more: Power Transformer-The Ultimate FAQs Guide
What's the Difference Between MVA and Mw?
The main difference between MVA and MW is that MVA is a unit of measurement for the amount of electrical load in an engineering system, while MW is a unit of measurement for the amount of power that is being generated or consumed.
Mw stands for megawatt, and it is equivalent to one million watts. On the other hand, MVA stands for megavolt-amperes, and it is equivalent to one million volt-amperes.
Mw is usually used to measure the power output of a generator, while MVA is used to measure the electrical load of a system. 10mva transformers are typically used to generate electricity for industrial businesses that require a strong and consistent source of power.
Try for free: How to purchase a 2 MVA power transformer?
How do you convert MW to MVA?
The equation to follow when converting megawatts (MW) to megavolt amperes (MVA) is as follows:
MVA = MW x 1,000 / Power Factor
The power factor is a value between 0 and 1 that indicates how efficiently electricity is being used. For example, if the power factor is 0.8, it means that the 10mva transformer is only using 80% of the electricity supplied to it.
When you convert 10 MW to MVA, you will get the following result:
10 MW x 1,000 / 0.8 = 12,500 MVA
This means that the 10mva transformer can handle a maximum load of 12,500 megavolt amperes.
Read on: The Ultimate FAQs Guide To 100 MVA Transformer
How Many Types of 10mva Transformers Are There?
There are three types of 10mva transformers: Dry-type transformers, Liquid filled transformers, and Air cooled transformers.
Dry-type 10mva transformer is the most commonly used type of 10mva transformer. The main feature of dry type 10mva transformers is that they do not require oil for cooling, which means there is no risk of fire or explosions. Dry-type 10mva transformers are also more efficient and have a longer lifespan than their oil-filled counterparts.
Liquid-filled 10mva transformers are filled with either mineral oil or silicone oil. The advantage of using Liquid filled 10mva transformers is that they can operate at higher temperatures than dry-type 10mva transformers. However, the downside is that they are more expensive and require more maintenance.
Air-cooled 10mva transformers are cooled by Air instead of oil. The advantage of using Air cooled 10mva transformers is that they are more efficient and have a longer lifespan than dry-type transformers and liquid-filled transformers. However, the downside is that they are more expensive than both dry types 10 MVA transformers and Liquid filled 10mva transformers.
At Daelim, we offer three types of transformers with 10mva power capacity types: power transformers, small substation transformers, and pad-mounted transformers.
10 mva power transformers are machines that step up or down the voltage in long-distance power transmission lines. This is because 10 mva power transformers have a higher capacity than substation transformers.
On the other hand, 10 mva substation transformers are used specifically for substations, which are the location where the voltage is transformed from high to low or vice versa. Therefore, 10mva substation transformers are mostly used by businesses and industries since they have a higher voltage capacity.
For pad-mounted transformers, the maximum capacity is usually 5000 kVA, while the capacity of Daelim's pad-mounted transformers can reach 7.5MVA and 10 MVA.
Get it now: 3 Phase Pad Mounted Transformer-Daelim Belefic
10 MVA Transformer Price
The price of the 10 MVA transformer is determined by factors such as voltage level, material, brand, standard, and accessories. The higher the voltage level, the more expensive the price of 10 MVA; the 10 MVA transformer with copper winding is about 30% more expensive than the aluminum winding; the 10MVA transformer of IEEE/ANSI, CSA, and other standards is more expensive than the IEC standard; the price of 10MVA provided by well-known brand transformer suppliers will be will be much higher. The brand and requirements of accessories will also directly affect the price of 10 MVA transformers.
The average price given here for a 10 MVA transformer is between $120,000 and $150,000. The precise price of a 10 MVA transformer requires you to consult a professional supplier. You can contact Daelim for a quick quote.
Reading more: The Ultimate Guide To 30 MVA Transformer
What Are the Specifications of a 10MVA Transformer?
The 10mva transformer has a variety of uses in different industries. It can be used for long-distance power transmission, substation, and industrial applications. Here are the 10 MVA transformer specifications according to Daelim standards:
Application: 10 MVA Power Transformer and Substation
Material: Insulating Oil, Mineral Oil PCB Free, Conductor, Copper
Number of Phases: 3-phase
kVA Rating: (ONAN) 10,00
% Impedance: AT 10,000 kVA
Rated Frequency: 60 Hz
Ambient Temperature (min/max): 40/-45°C
Volts (V): 4,160
Amps (A): 1,387.86
Between: x1, x2, and x3
Tank Pressure: +8 PSI / -14.7 PSI / +55 kPa / -101 kPa
Weight of Insulating Oil: ~2,850 L
Total 10 MVA Transformer Weight: 14,000 kg
What Are the 10 MVA Transformer Nameplate Details?
Attached below are images of the 10 MVA transformer nameplate details:
The 10mva transformer is designed in accordance with the CSA C88-16 standard. It was recently exported to Canada.
The 7.5/10.5mva transformer is designed and manufactured in accordance with the IEC60076 standard. It was exported to Ecuador the previous year and is currently used for normal operations.
10 MVA Transformer Weight
Below is the weight of three types of 10 MVA transformers produced by Daelim for your reference.
69 kV 10 MVA power transformer weight 23470 kg.
25 kV 10 MVA small substation transformer weight 14000kg.
24900GrdY/14400 10 MVA pad mounted transformer weight 15000kg.
10 MVA Transformer Nameplate Details
The nameplate is on every transformer. So let's take a look at the information on the nameplate of the 10 MVA transformer.
The picture on the right is the nameplate picture of the 10 mva transformer exported to Canada by Daelim, and it can be seen that it mainly contains the following information
Voltage Tating: HV 25000V; LV:4160 V
Insulation Level (kV): HV: 150/50; XV:30/10;XVN:30/10
kVA Rating: ONAN 10000
% Impendance:
Sound Level: 65 dB
Material : Copper
Rated Frequency: 60Hz
Cooling Method: ONAN
Weight: Total 1400kg; Insulating oil 2850L
Temperature Rise: Oil 65°C; Winding 65°C
Ambient Temperature: Max 40°C; Min -45°C
Electrical Connection Diagram
Tap Changer Gear Voltage
Tank Pressure: +8 PSI / -14.7 PSI /+55 kPa / -101kPa
Applied Standard: CSA C88-16
Serial No,
Line MFG.NO.:
Date Of MFG:
Related Article
How To Read A Transformer Nameplate?
10 MVA Transformer Dimensions
The dimensions of the 10mva transformer designed by different transformer manufacturers will be different. This is determined by different technical requirements and engineer experience. The following table is Daelim 10 MVA transformer dimensions.
| 24900GrdY 10 MVA Pad Mounted Transformer Dimensions | ||
| Height | Depth | Width |
| 2900mm | 2800mm | 2700mm |
| 69 kV 10 MVA Power Transformer Dimensions | ||
| Height | Depth | Width |
| 3890mm | 5270mm | 4080mm |
What is the 10 MVA Transformer Oil Capacity?
The tank capacity of a 10 MVA transformer is approximately 3,383 gallons. Therefore, a 10 MVA transformer can store up to 3,383 gallons of insulating oil. It should be noted here that the oil capacity of a 10MVA transformer will vary depending on the type and design. The 10 MVA transformer also has an oil conservator which prevents oil from foaming.
At the same time, the 10 MVA transformer is also equipped with an oil gas separator. The oil gas separator helps to remove any dissolved gasses in the insulating oil. These gasses can cause the 10 MVA transformer to malfunction.
The 10 MVA transformer can function properly and efficiently with the oil gas separator.
When Do You Need a 12 MVA Transformer?
In most cases, a 10 MVA transformer is more than sufficient. However, in some cases, a 12 MVA transformer may be required. 12 MVA transformers are usually used in areas where the load is extremely heavy. This power transformer is equipped with an on-load tap changer (OLTC) that helps to optimize the voltage output.
Daelim's 12 MVA power transformer is designed using advanced transformer technology. This results in a smaller footprint and reduced noise levels. We also used high-quality materials and components to ensure that our 12 MVA transformer is durable and long-lasting.
Daelim ensures that each 12 MVA power transformer we produce passes the full acceptance test. This includes a transformer load, dielectric, and sound level test. In addition, we strive to guarantee 0 fault rates so our valued customers can have peace of mind when using our products.
Our oil-immersed 12 MVA power transformer is suitable for both indoor and outdoor installations. It can be used in various applications, such as power plants, substations, and industrial facilities. It's designed in accordance with the IEC60076, ANSI, NEMA, and other major international standards.
3.5 MVA transformers have a rated power of 3,500 kVA and are used for single-phase two-wire applications. It is also used as a three-phase, four-wire transformer. A 3.5 MVA transformer can be used in industries, factories, and other commercial applications.
A 3.5 MVA power transformer is an industrial-grade transformer used in various settings, such as manufacturing plants and industrial warehouses. This particular power transformer is designed to meet the demanding needs of these types of businesses.
Daelim's 3.5 MVA pad-mounted transformer features an iron core with high-quality silicon steel in cold-rolled sheets. This results in a durable, long-lasting transformer that complements well with oxygen-free copper. The transformer has the advantages of a compact structure, tamper-proof design, and low maintenance cost.
The 3.5 MVA power transformer also has a copper winding that is electrically insulated with varnish. This feature ensures that the transformer can withstand high temperatures and humid conditions.
Reading on: The Ultimate Guide to 2500KVA Transformer
15 MVA Transformer
10 MVA transformers are typically used for larger businesses and establishments. However, in some cases, a 15 MVA transformer may be required. 15 MVA transformers are high-performing ones that usually carry higher loads, which is why they are commonly integrated into the local power grid.
Daelim's 15 MVA Transformer is 100% customizable to ensure that it can optimize power distribution for your specific needs. In addition, we use the latest transformer technology to design our 15 MVA transformers. This results in a smaller footprint and reduced noise levels.
The Daelim 15 MVA Transformer is the only transformer that doesn't require additional transformers installed within it. This feature ensures internal space and easy maintenance. Our 15 MVA transformer can operate at a powerful 1,500 voltage input.
We use high-quality materials and components to ensure that our 15 MVA transformers will provide optimum performance for years to come. Daelim also conducts a full acceptance test for each 15 MVA transformer we produce.
Get it now: Surplus 15000 kVA transformer for sale!
10/12.5 MVA transformer
A 10/12.5 MVA transformer is a high-performing power transformer that can be used in various settings. 10/12.5 MVA transformers are typically used for large business applications and establishments. This is because it can generate sufficient power to meet the demands of these types of businesses.
Daelim's oil-filled 10/12.5 MVA transformer is perfect for substation step-down applications. It is also an excellent choice for industrial facilities and power plants. This 10/12.5 MVA transformer is designed to meet the IEC, NEMA, and ANSI standards.
With an 8.08% Impedance, the 10/12.5 MVA transformer can be used with various voltages. It has a copper winding and an iron core that is made of high-quality silicon steel. This 10/12.5 MVA transformer also features electrical insulation that can withstand high temperatures, humid conditions, and other harsh environments.
Read my article How Much You Know To Purchase The 12.5 MVA Transformer In 2022?
What are the Different Applications of a 10 MVA Transformer?
10 MVA transformers are typically used for big factories and plants that require a large and consistent power supply. In specific industries, 10 MVA transformers are useful for the transport, electronics, and chemical industries. 10 MVA transformers can also be used in a variety of settings, such as:
Manufacturing plants
Industrial warehouses
Substations
Power plants
And more!
Daelim 10 MVA transformers are some of the most versatile and reliable transformers on the market. With a 10 MVA transformer, you can be sure that your business will have a consistent and reliable power supply.
What Are the Different Types of 10 MVA Transformer Cores?
The 10 MVA transformer is a distribution transformer that can help generate electricity for large establishments outside of a residential property. The 10mva transformer typically has three types of cores:
Iron core
Ferrite core
Toroidal core
Iron cores are the most common type of 10mva transformer cores. They are made of high-quality silicon steel and are designed to be durable and long-lasting. Iron cores are also less expensive than other types of 10mva transformer cores.
Ferrite cores are made of a mixture of iron and ceramic. They are less magnetic than iron cores and less likely to cause interference. Ferrite cores are more expensive than iron cores, but they offer better performance.
Toroidal cores are made of a donut-shaped piece of iron. They are the most expensive type of 10mva transformer cores, but they offer the best performance. Toroidal cores are less likely to cause interference and are more efficient than other types of 10mva transformer cores.
Conclusion
Through the above introduction, I believe you have a deep understanding of the type, price, weight, size, brand name, etc. of 10 MVA transformer. If you need to know more, you can contact Daelim, there will be a very professional team to answer your questions.
